Product name: VAG COMMANDER 8.6,VAG VVDI Interface,VAG Vehicle Diagnostic Interface VVDI

Supported language: English

VVDI immo plus latest version: V18.0

we can free update for you if your Vag commander vvdi are bought form China, please contact our sales.

1. Additional features added MED17/EDC17 OBD read PIN, CS, MAC functions. You can also use eeprom and flash access

2. pairs NEC +24 C32 and NEC +24 C64 part of the model can be lost at all without dismantling the instrument directly OBD generate the key can be activated at all lost key interface with select button

3. generates four generations theft OEM keys, for the use of 48 chips, dealers in key generation process will be prompt. Need to rewrite the ID 48 chip, the need to use the five-generation programmer. Five generations of programmers need to upgrade.

4. generates A4L/Q5 OEM key (the key is generated when the dealer will be prompted), unlocking OEM key (re-key chip interface). Requires a special OEM keys and five generations Programmer

5. Add more automatic vehicle identification

6. This version needs to be upgraded in order to run the latest version of firmware

7. bug repair

Function:

1) Extracting security access codes (PIN) by OBDII

2) Programming keys by OBDII. Preparation of dealer's keys.

3) Mileage recalibration by OBDII

4) Clearing crash data DTCs by OBDII

5) Read/Program flash memory of engine control units by OBDII. Options for resetting the number of flashing attempts.

6) Exchange speed limit of MMI-TV system

1.Standard diagnostic functions:

1) Connect to the device using KWP2000 over TP2.0, KWP2000 over TP1.6, UDS over ISO transport protocol (CAN), KWP1281 or KWP2000 over K-Line

2) For all electronic control units reading identification data

3) For all electronic control units read error (DTCs)

4) For all electronic control units clear error (DTCs)

5) Scan all units

6) Broadcast requests

7) Measured values

8) Adaptation

2.Special functions:

1) Instrument CAN

(1) With this function you can establish diagnostic session with the Instrument cluster using KWP2000 over TP2.0

(2) You can read current odometer value

(3) You can change odometer value

(4) Added support for VDO Instrument Cluster 2006+

(5) Read/Program memory of instrument cluster immobilizer

(6) Reading security access code of the IMMOBILIZER

(7) Read/Write immobilizer related data

2) EZS - Kessy (Q7/A6/Allroad)

(1) With this function you can prepare dealer key/learn dealer key

(2) Read/Write EEprom from EZS - Kessy (Q7/A6/Allroad)

3) Instrument K-Line

(1) With this function you can establish diagnostic session with the Instrument cluster via K-Line (KWP1281 or KWP2000)

(2) You can Read/Change odometer value

(3) Read PIN code

(4) Read/Write EEprom

(5) Read ROM/Flash from the Instrument cluster

4) Engine Control Unit

(1) Read EDC17/MED17 flash memory

(2) Read/Write of flash memory (EDC15, EDC16 all types Read/Write Flash memory via OBDII (K and CAN). Calculation of checksums while programming, ME7.1.1, MED9.x, ME7.5)

(3) Read/Write flash counters (EDC16)

(4) Read/Write EEprom (VAG-EDC15x, VAG-ME7.1.1, VAG-ME7.1, VAG-ME7.5, VAG-Cartronic ME7.8.)

(5) Extracting Security access code / PIN (EDC15, ME7.x, VAG-Cartronic ME7.8, EDC16, EDC17, MED9.x, Simos PPD)

(6) Extracting Component security bytes (EDC15, ME7.x, VAG-Cartronic ME7.8, EDC16, MED17.5.1, MED 9.x, Simos PPD)

(7) Enable/Disable immobilizer (EDC15, ME7.x, EDC16)

(8) Odometer correction (EDC15, EDC16)

5) Kessy adaptation

This function can be used for adaptation of brand new kessy units to the car. This adaptation can be by CAN TP2.0, K-KWP2000 and also can be used with Porsche Cayenne.

6) TV activation ED1/ED2

(1) Using this special function you can change speed limit of MMI compatible vehicles to change speed where TV becomes OFF

7) Key learning

With this function you can learn key/transponder to the vehicle

8) Dump tool

With this function you can calculate security access codes, change odometer and so on from EEPROM dump from the corresponding unit

9) Airbag

With this special function you can Read/Write EEPROM memory of the airbag module

Clear the crash data of the airbag module

10) Custom Read/Write

Using this application you can read/program memory in some electronic control unit

11) PIN Convertor

12) Service interval

Using this function you can perform reset of the service reminder, reset of the service interval parameters or change service interval options

13) Remote control adaptation

Using this application, you can learn remote controls

14) Navigation

Using this application, you can enable/disable the "Eject" button of the "Navigation" system

15) Cruise control system

Using this application, you can activate/deactivate a cruise control system and change the related

steering wheel electronics( SWE) configuration if SWE unit is available

Function in addition:

1.According to obd2, the latest VVDI supports nec 24c32 mileage change, dealer key generation, EPPROM data reading & writing, FLASH backup.

2. According to obd2, the latest VVDI supports GOLF6 MM7 (9S12) mileage change, dealer key generation, EPPROM data reading & writing, FLASH backup.

3. Add the function of professional TA chip pre-program, it directly pre-programs 48 chips into TA2, TA3, TA4, and TA5.

Support Car List:

1 AN002 - KM-CAN

1 AN003 - PIN-CAN

1 AN004 - IMMO panel

1 AN005 - IMMO panel EDC16

1 AN006 - KM/PIN K-Line

1 AN008 - Flash Counters

1 AN009 - Key learning

1 AN010 - Airbag EEPROM

1 AN011 - TV Activation

1 AN012A- EDC16 Odometer

1 AN012B- EDC16 EEP/PIN/IMMO-off

1 AN014 - EDC17 EEPROM

1 AN015 - Flash Memory ECU

1 AN016 - Dealer key learning

1 AN018 - Dealer key learning Q7

1 AN019 - Prepare Dealer Key Q7

1 AN021 - ME7 EEPROM by CAN

1 AN022 - CDC32xx Programmer

1 AN027 - Q7 2008


Notice:

IMMO PLUS 2.0 software and VAG COMMANDER software is allowed to run with a same hardware, but our old VVDI users need to update the hardware firmware before running IMMO plus software with the VAG COMMANDER hardware.

Before update, you have to use COMMANDER UPDATE 1.3 software to read out serial number and send it to your supplier. After your supplier send you the updating data file, please also use COMMANDER UPDATE 1.3 software to open it, then update the hardware, you need only click the button "UPDATE", then a dialog box appears, then you just open the data file. Attention:

How to update Vag commander:

1. Please download the software "Commander update V1.3 "; you can download from this link:

2. Give us the serial number;

3. Then we will send the updated software to you via email.

Vag VVDI latest update immo plus 5.0.0, VVDI software setup

Package including:

1.Vag box

2.16pin connector

3.OBD2 cable

4.Tag cable

5.CD
